QNAP QGD-3014-16PT-8G 16-Port, Smart Edge PoE Switch, NAS, NVR, Router Appliance

$1,339.00 inc. GST

Desktop Smart Edge PoE Switch, Cost-optimized intelligent IP surveillance solution

Available on backorder

SKU: QGD-3014-16PT-8G Categories: , , , ,

Description

The QNAP QGD-3014-16PT-8G Desktop Guardian PoE managed switch has sixteen 30-watt Gigabit PoE ports, two Gigabit SFP/RJ45 combo ports and two 2.5GbE host management ports. With a dual-processor design including an Intel® Celeron® J4125 quad-core 1.8GHz processor and four 3.5-inch SATA drive bays, the QGD-3014-16PT meets requirements for high-speed transmission, storage space, and virtual machine performance in surveillance applications. Supporting VMs and QTS for versatile applications such as QVR Pro, HBS 3 and QuWAN, the QNAP QGD-3014-16PT-8G combines surveillance deployment, video storage computing, remote backup and WAN optimization to create intelligent surveillance infrastructure and remote backup solutions.

  • Compliant with the IEEE 802.3at PoE+ standard and includes sixteen 30-watt Gigabit PoE ports. Supplies a total power budget of 140 watts to meet the demands of high-powered devices (PDs) and supports smart PoE management.
  • Provides comprehensive Layer 2 management features, such as VLAN, LACP, QoS IGMP Snooping, and Wake-on-LAN for IT staff to efficiently control network bandwidth and enhance security via the user-friendly switch management web interface.
  • Supports up to four SATA SSDs or HDDs.
  • Supports real-time transcoding and has HDMI 2.0 output for direct 4K 60Hz surveillance video playback.
  • Supports local, remote and cloud backup; centralizes management; and strengthens 3-2-1 backup planning for disaster recovery.
  • Directly host containers and virtual machines to run various applications. Flexibly install QuWAN SD-WAN, virtual routers, firewalls for various networking management applications.
  • Increase capacity by connecting a QNAP REXP-1000 Pro expansion unit



Next-Generation Intelligent IP Surveillance and Remote Backup Solution

Modern enterprises need to deploy surveillance systems in various sites with multiple IP cameras, switches, NAS/NVR, and then transmit local data to central servers. This can often be a complicated, inefficient, and expensive process. The QGD-3014-16PT integrates PoE power capabilities, surveillance server, and data backup management, thus simplifying the software and hardware requirements and increasing the transmission and backup efficiency of surveillance videos.

Complete Surveillance Infrastructure Deployment for Smart Retail

Combining QVR Pro surveillance software, HBS remote backup, and QuWAN SD-WAN solutions, the QNAP QGD-3014-16PT-8G is a total package for surveillance deployment. Businesses can centrally manage video capture, playback, and processing to benefit from a cost-optimized smart surveillance solution.

  • PoE power: 15–30-watt Gigabit PoE capabilities to high-power IP cameras.
  • Camera management: QUSBCam2 allows using USB cameras and webcams as ONVIF® cameras.
  • Virtual network: Two 2.5GbE host management ports provide bandwidth for virtual networking.
  • Storage backup: Install four 3.5-inch SATA drives to attain large storage space for backup.
  • Surveillance server: QVR Pro is compatible with a wide range of ONVIF® IP cameras and allows central management of live feeds and recordings.
  • Video output: Connect the QGD-3014-16PT via HDMI output to a 4K display for direct playback of security footage.
  • Surveillance video: Simultaneously view live feeds and recordings via the QVR Pro Client
  • Fiber uplink: 1GbE SFP/RJ45 combo port to connect to a backbone network or data center.
  • Remote VPN: Supports the QuWAN SD-WAN encrypted VPN network for secure connection.
  • Mobile monitoring: Universally access recordings and feeds with the QVR Pro Client mobile app.
  • Central management: Use QVR Center to manage multiple instances of QVR Pro.
  • Remote Backup: HBS 3 enables you to back up recordings and transfer data from one QGD-3014-16PT to a remote QGD-3014-16PT, QNAP NAS, remote server or cloud storage.
  • Surveillance failover: QVR Guard automatically takes over recording tasks if a QVR Pro server fails.

Additional information

Weight5.34 kg
Dimensions282 × 384 × 78 mm
Network type

10GbE, 1GbE, 2.5GbE, SFP+

Network Connections in Total

18

Chassis

Desktop

Power Supply

Single

Warranty

2 years

HDD Bays

4

HDD type

2.5", 3.5", M.2, SATA 6Gbps

CPU Family

Intel Celeron

CPU Frequency

2.00 GHz

CPU # of cores

4

System Memory Installed

8GB

System Memory Maximum

8GB
